8 colors Flexographic Printing Machine Roll to Roll Paper UV Press With servo control

8 colors Flexographic Printing Machine Roll to Roll Paper UV Press With servo control supplier
8 colors Flexographic Printing Machine Roll to Roll Paper UV Press With servo control supplier

8 colors Flexographic Printing Machine Roll to Roll Paper UV Press With servo control

Product Details:
Place of Origin: Made in china
Brand Name: XIAOHAI
Certification: CE ISO
Model Number: YH
Payment & Shipping Terms:
Delivery Time: 30 days
Contact Now

Detail Information
Video Link: Http://youtu.be/9AJWobKSvWg

Product Description

1. Specifications:

flexo machine
roll to roll
resin plate
to printing various material

STANDARD FUNCTION DEVICES:
unwinding station
electronic rectifying systemimported from America
unwinding braking systemmagnetic powder braking-imported original
manual tension control unit
printing unit
output tension unit
still image inspecting system(imported from America)
catwalk
rewinding unit

OPTIONAL FUNCTION DEVICES:
cassette design in printing stations
non-stop changing unwinder
anti-static bar
corona system
delam & relam self-adhesive labels
reverse printing with turn bar
UV glazing system
cold lamination/foil stamping
vacuum web cleaner
ink pump
enclosed doctor blade system
rotary die-cutter
creasing/embossing/punching/fan-folding
sheeter
slitting
electronic hoist
multiple waste take-up
conveyor
rear rectifying systemimported from America
2nd pass printing
in-line gravure/screen printing



2.Technical Parameters:



MODEL

WIDE WEB SERIES



YH810

YH1000

YH1200

Max.Web Width

825mm

1015mm

1215mm

Max.Printing Width

810mm

1000mm

1200mm

Max.Die-cut Width

810mm

1000mm

1200mm

Printing Repeat Length

260-710mm

260-710mm

260-710mm

Die-cut Repeat Length

260-710mm

260-710mm

260-710mm

Max. Unwinder Diameter

1524mm

1524mm

1524mm

Max. Rewinder Diameter

1524mm

1524mm

1524mm

Gearing Size

1/8CP

1/8CP

1/8CP

Max. Mechanical Speed

152m/min

152m/min

152m/min

OD of Web Roller

100mm

100mm

100mm

Main Drive

Motor

15-18kw

20-30kw

20-30kw

Lubricating System

auto

auto

auto

Air Pressure

0.6mp

0.6mp

0.6mp

Power Required
