China Face mask making machine manufacturer

hamburger box pasting machine

Product Details:
Place of Origin: China,Wenzhou,Ruian
Brand Name: XIAOHAI
Contact Now

Product Description

hamburger box pasting machine


This machine is high effciency, reliable quality and long service life.

We Are carton erecting machine Machines

800A Take Away Food  Box Forming Machine Advantage:

1.Feature of stereo box die-cutter: high efficiency, reaches 180pcs/min

2.Multifunctionality: can manufacture the products such as meal box, chips box, stereo box or burger box with different specifications on one machine only by changing its molds.

3.This machine applies water-based adhesive coating device, attains high efficiency and very high precision. Water-based adhesive, as water soluble adhesive compostion, is a kind of food-grade glue.

4.Most of the machine applies high-quality sealing bearing, prevents from dust or liquid penetrating and impacting the service life of bearings, with long service life and good stability.

5.The whole is driven by high-quality tinming belts and ensures almost zero error during its operation.

6.Main mould employs pine wood, enjoys high efficiency when replacing its mould.

7.Can automatically collect, store and count finished products, and install additionally counter as per the requirements of customers.

8.The machine applies PLC intelligent control system, and automatically stop when there is paper jamming or no paper. It can avoid unnecessary harm caused by the contact between worker and operation mechanism during the production process.

hamburger box pasting machine

Technical Data:

Model No.

HBH-800A

Productivity

max 180pcs/min

Material

 200-600gsm cardboard

Paper thinkness

 max 1.5mm

Electricity required

 3kw/hr

Air requried

 6kg/cm²*200L/min

Productivity

  Glue Sealing

 Overall size

3450mm*1250mm*1480mm

 Weight

2000kgs

welcome to contact us

hamburger box pasting machine
