China Face mask making machine manufacturer

SMS Non woven surgical protection gown production line

Product Details:
Place of Origin: Made in china
Brand Name: XUANHAI
Model Number: FHF
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: seaworthy package
Delivery Time: according to the machine,30 days.
Payment Terms: 30% downpayment and pay the balance before shipment afer test the machine in our factory.
Supply Ability: 10SETS
Contact Now

Detail Information

Video Link:: Https://youtu.be/J4OaSyRsoxU

Product Description





1.Gown body making machine



Fully automatic protective gowns body making machine, from material feeding to belt welding, neckline cutting, folding, cuff cutting, shoulder welding, forming and cutting, etc. No need any manual operation and only requires one worker to operate it. At the same time, it is the first in the industry to realize that the nailing function can be turned on selectively to achieve the dual-use of one machine and two products and it replaces most of the traditional manual processes.





Main Features



1) High production and excellent performance, one machine can make different sizes.



2) From material feeding to belt welding, neckline cutting, folding, cuff cutting, shoulder welding, forming and cutting,etc.

3) PLC, touch screen, full servo motor control, easy operation



4) Automatic EPC and tension control, aluminium ally frame, stable and durable.



model
FHF-001




speed
15-30pcs/min

voltage
220v or 380v

total power
10kw

net weight
2500kg

machine dimension
8000x2100x2500mm

raw material roller diameter
500-1000mm

raw material roller material width
1450-1600mm

raw material feeding system
Auto





2. Sleeve making machine



Fully automatic protective clothing sleeve making machine, it is a machine which can produce the disposable medical protective gowns sleeves automatically, the process is from raw material feeding, add the elastic band & welding to final products welding and cutting. It only requires one worker to operate. Base on the actual reasonable layout design, saving the fabrics at the maximum.



    Main Features





1) High production, compact structure and easy operation.





2) Photoelectric detection and automatic stop of the machine when material running.





3) PLC, touch screen control, easy operation, reliability and high performance.





4) The finished product looks beautiful and trendy.



 Specification:



 Max.Speed 60-80 pes/min

 Voltage 220V 50hz

 Power 4kw

 Machineweight 1650kg

Machine dimension 3860*1600*1 750mm (L*W*H)



3. Manual Surgical gown ultrasonic sewing machine



Frequency (Khz) 20KHZ

Voltage (V) 220V 50HZ

Working speed 10-15m/min

Machine size 800*800*1200mm

Machine weight: 80KGS
