Product Details:
|
|
| Place of Origin: | Made in china |
|---|---|
| Brand Name: | xiao hai |
|
Payment & Shipping Terms:
|
|
| Delivery Time: | according to the machine,10-30 days. |
| Payment Terms: | 30% downpayment and pay the balance before shipment afer test the machine in our factory. |
Product Description
| Core Benefits of Cushion Air Column Bags
|
If one column of the bag is broken or torn, the other columns will remain intact, as each column is independent.
inflatable air column bag making machine
NO.1 Model QZ-1200 (roll type)
Technical Parameters:
Membrane Roll Size: Max. roll width: 1250mm
Max. roll diameter:500mm
The Highest Speed of Column Pressing:
18 cycles/min.(Speed adjustable)
20 mm column- 14 columns per pressing
30 mm column- 10 columns per pressing
40 mm column- 7 columns per pressing
60 mm column- 5 columns per pressing
The Max. Width of Pressed Column: 1220mm
Column Pressing Parameters: Realized via PLC control panel for column pressing speed, welding temperature, pressing time, standards compensation, etc.
Power consumption: 15.2 kw
Air supply: 0.68MPA
Weight: 2800kg
Dimensions: 5320 X 1800 X 1680 mm
inflatable air column piece bag cutting machine
NO.2 QZD-800 ( bag piece by piece)
Membrane Roll Size:
Max. roll width: 1250mm
Max. roll diameter:400mm
Speed : 24-35 pcs/min.
Max. Bag length: <900mm
Max. Bag width: <750mm
Bag Making Parameters: Realized by PCL control panel for setting pressing time, pressing temperature, standards compensation, roll-unwinding, automatic variation correction system
Power consumption: 2.7 kw
Air supply: 0.65MPA
Weight: 1800kg
Dimensions: 4400 X 2400 X 1480 mm
