Product Details:
|
|
| Place of Origin: | Zhejiang |
|---|---|
| Brand Name: | Xiaohai |
| Model Number: | YD-169 |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1 set |
| Packaging Details: | sea worthy package |
| Delivery Time: | 20-30 days |
| Payment Terms: | 30% TT |
| Supply Ability: | 20 sets |
Product Description
1,APPLICATIONS:
The machine is suitable for the dual bag packing of small grain-like materials, such as tea leafs, medicinal tea and healthy teas.
2,FEATURES:
AUTOMATIC TEA-BAG PACKING MACHINE WITH THREAD,TAG AND ENVELOPE is a hot-sealed,automatic and multifunction packing equipment ,The main characteristic of this equipment is it can molding in one time to protect the material from the direct contact with workers’hands and improve the efficiency. The inner bag is filter paper ,tagging with thread and label automatically is available.The outer bag is composite paper (including various kinds of composite membrane hot sealable such as paper/plastic, plastic/plastic, plastic/aluminum/plastic, paper/aluminum/plastic.) The most advantage is ,the capacity ,the inner bag and outer bag can be adjuster flexibly,and the size of the inner and outer bag also can be adjuster according to the requirement of the customer to get the perfect effect.
3. TECHNICAL DATA:
MODEL | YD-169 |
FEATURES | The inner bag with thread and tag automatically, three side seal |
FILLING RANGE | 1-15g/bag |
CAPACITY | 30-40(bag/min) |
INTER BAG SIZE | L:50—75mm W:50—75mm |
OUTER BAG SIZE | L:85—120mm W:75—95mm |
TAG SIZE | Width: 40-50mm |
THREAD LENGTH | 155(mm) |
POWER | 220V/50HZ single phase |
TOTAL POWER | 3.7kw |
DIMENSION | 1400X900X1750( L* W* H mm) |
WEIGHT | 650KG |
Machine pictures:
Main Parts List:
Name | BRAND | Mode | Quantity | Note |
Transdcer | Panasonic | BVF00042G | 1 | warranty period 3 years |
Transdcer | Panasonic | BVF00072G | 1 | warranty period 3 years |
PLC | Panasonic | FP0-C16T | 1 | warranty period 3 years |
Touch-screen | TEWEI,Canada | TP460-L | 1 | warranty period 3 years |
Temperature control instrument | Japan OMRON CO.LTD | NG-6411V-2 | 1 |
|
Rotary encoder | Japan OMRON CO.LTD | OSS-036-2CH | 1 |
|
Switch power supply | WEIMING,taiwan | S-50V | 1 |
|
Photo switch | YA TAI,CHINA | GDJ-211G | 1 |
|
Airciruitbreaker | LG | BKN-3P/32A | 1 |
|
Airciruitbreaker | LG | BKN-1P/32A | 1 |
|
Airciruitbreaker | LG | BKN-1P/10A | 3 |
|
Airciruitbreaker | LG | BKN-3P/32A | 1 |
|
Alternating current contactor | Schneider | MY-2NY | 1 |
|
Alternating current contactor | Schneider | MY-2NY | 1 |
|
Proximity switch | Schneider | TL-Q5MC1 | 2 |
|
Thermocouple | Schneider | E 3M | 2 |
|
Thermocouple | Schneider | E 3M | 2 |
|
Operating button | Japan OMRON CO.LTD | Y090-11/R | 2 | With light AC220V |
Operating button | Japan OMRON CO.LTD | Y090-11/G | 3 | With light AC220V |
Operating button | Japan OMRON CO.LTD | Y090-22X/N/33 | 2 |
|
Operating button | Japan OMRON CO.LTD | Y090-11TS | 1 | emergency stop |
