GL Series coffee capsules filling and sealing machine

Product Details:
Place of Origin: China
Brand Name: Xiaohai
Model Number: GL
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Packaging Details: Seaworthy Package
Delivery Time: 30-45 days
Payment Terms: 30% downpayment and pay the balance before shipment afer test the machine in our factory.
Supply Ability: 20 Sets per month
Contact Now

Product Description



GL Series coffee capsules filling and sealing machine



INTRODUCTION OF EQUIPMENTS:



   1. Usage:

GL series coffee capsule filling and sealing machine is used for coffee capsules filling with coffee powders(or other kinds of powder products like tea powder, milk powder, rice, wheat powder, cocoa powder etc. )



We have successful experience design machines according to customer’s requirement. The machine absorbing advanced technology in the world, is the new generation of the automatic filling and sealing machine. It has the characters like Omron PLC control,reasonable design, compact structure, beautiful appearance, stable and reliable performance, high filling accuracy, adaptability, simple operation, easy maintenance, cleaning and convenient.



  2. Characters:

1. automatic feed coffee capsules/cups onto machine conveyor belt

2. automatic fill coffee powder as precise weight 3g, 5g,7g, 10g etc and press the powder tightly.

3. automatic feed foil and twice heat seal .

4. automatic output final capsule/cup (could connect to conveyor belt)



  3. Main Technical Parameters:

Machine Model

GL-4

GL-8

GL-16

Suitable Product

Powder product as coffee, chocolate, tea, milk powder, sugar etc.

Suitable film

Precut foil suggested (film roll also available)

Capacity

1440 pcs/hr

2880 pcs/hr

5800 pcs/hr

Filling range

3g,5g,7g.10g etc adjustable

Voltage

380V/220V 50hz design upon your needs

Power

4.5Kw

6.5Kw

10Kw

Dimension (LxWxH)

3000X760X1650(mm)

3000X930X1650(mm)

3000X1580X1650(mm)

Weight

800Kg

950Kg

1100Kg



 The mould of the machine for the coffee cup is made according to customers’ cup.

 The machine can be customized depending on your requirements.

 So if you have any demands, please let me know.
